VRD ДВУХЛИНЕЙНЫЙ РЕГУЛЯТОР РАСХОДА С ФИКСИРОВАННОЙ НАСТРОЙКОЙ (OLEOWEB, ИТАЛИЯ)
COMPENSATED FLOW RESTRICTORS 2 WAYS, ADJUSTABLE, WITH FREE REVERSE FLOW
The compensated flow control valves VRD are commonly employed in order to control the lowering speed of an hydraulic actuator, independently by the pressure due to the working load.
DESCRIPTION
The adjustable, pressure compensated flow control valves VRD are normally installed on the bottom of a simple effect hydraulic cylinder in order to guarantee a constant lowering speed lin every working condition. This is possible thanks to the presence of the hydraulic compensator which manages a constant outlet flow from the valve even in presence of pressure variations due to the working load. These valves allows also the feeding flow to the cylinders without compensation. The compensated flow regulator VRD can manage working flows rate between 2 lpm (0,52 USgpm) and 150 lpm (39,6 USgpm) according with the size of the valve. VRD series is dividev in four sizes following the dimension of the external thread BSPP: ¼”, 3/8”, ½ e ¾”. The manual adjusting of the flow is allowed into setting ranges available for each size. The maximum working pressure for VRD series is 300 bar (4350 PSI). Thanks to the adjusting nut it is allowed to obtain fine settings for valves of VRD series, recovering eventual tolerances present into the hydraulic system. The compensated flow control valves VRD are fitted into cavities with female thread BSPP according with the choosen size.
ЕСЛИ В ТАБЛИЦЕ НИЖЕ ПОКАЗАНО, ЧТО ИНТЕРЕСУЮЩАЯ ВАС ПРОДУКЦИЯ В НАСТОЯЩИЙ МОМЕНТ ОТСУТСТВУЕТ НА СКЛАДЕ, ВЫ МОЖЕТЕ ОБРАТИТЬСЯ К СОТРУДНИКАМ МАГАЗИНА ГИДРАВЛИКИ RM316.RU ДЛЯ УТОЧНЕНИЯ СРОКОВ ПОСТАВКИ ТОВАРА.
Компания Oleoweb (Италия) производит гидравлические комплектующие: гидрозамки, предохранительные и обратные гидроклапаны, гидравлические клапаны последовательности, тормозные гидроклапаны, ручные гидронасосы, диверторы гидравлические, шаровые краны высокого давления, гидравлические плиты CETOP для гидрораспределителей и многое другое. В нашем магазине гидравлики можно купить со склада или заказать любую продукцию Oleoweb по низким ценам. Осуществляем оперативную доставку гидрокомпонентов Oleoweb по всей России.
Техническая документация
Загрузите наш каталог в pdf формате 365.2 KBДоставка
